Pvc Coated Wire Rope
PVC Coated
Main Applications: Widely used in automobiles, ship building, construction industry and all needs of outdoor applications or special working environment.
Mainly used in mine hoist cage, meat processing plant, upgrade machinery, ship anchors and fishing operations, fishing vessels trawling.
| Nominal
Diameter (mm) |
Minimum Breaking Strength (kN)
Nominal Tensile Strength (N/mm²) |
Approx N.W.
(kg/100mtr) |
|
|---|---|---|---|
| 1770 N/mm² | 1960 N/mm² | ||
| 2–3 | 1.48 | 1.64 | 1.57 |
| 3–5 | 3.33 | 3.69 | 4.08 |
| 4–6 | 5.92 | 6.56 | 6.29 |
| 6–8 | 13.3 | – | 12.22 |
| 8–10 | 23.7 | – | 20.2 |
| 10–12 | 38.8 | – | – |
| 12–14 | 54.2 | – | – |
| Nominal
Diameter (mm) |
Minimum Breaking Strength (kN)
Nominal Tensile Strength (N/mm²) |
Approx N.W.
(kg/100mtr) |
|
|---|---|---|---|
| 1770 N/mm² | 1960 N/mm² | ||
| 2–3 | 2.35 | 2.6 | 2 |
| 3–5 | 5.29 | 5.86 | 5.04 |
| 4–6 | 9.41 | 10.4 | 8 |
